- Part: MG723TC24SW
Instrument bracket for motogadget's Classic / Chronoclassic, fits selected Triumph (air cooled) triple clamps, black
Learn More$62.00 - Part: MG2007002
black LCD, black housing
Learn More$529.00 - Part: MG2004056green LCD, black housing, black bezel Adapter Learn More$538.00
- Part: MG2004051green LCD, black housing, black bezel Adapter Learn More$538.00
- Part: MG2004048green LCD, black housing, black bezel Adapter Learn More$538.00
- Part: MG2004066black LCD, black housing, black bezel Adapter Learn More$538.00
- Part: MG2004061black LCD, black housing, black bezel Adapter Learn More$538.00
- Part: MG2004058black LCD, black housing, black bezel Adapter Learn More$538.00
- Part: MG2004065black LCD, black housing, polished bezel Adapter Learn More$538.00
- Part: MG2004060black LCD, black housing, polished bezel Adapter Learn More$538.00
- Part: MG2004055green LCD, black housing, polished bezel Adapter Learn More$538.00
- Part: MG2004050green LCD, black housing, polished bezel Adapter Learn More$538.00
- Part: MG2004049green LCD, black housing, polished bezel Adapter Learn More$538.00
Details
The motogadget chronoclassic is a digital multi-purpose instrument in a classic round casing.
Technically identical to the motoscope classic, it brandishes a black dial and a white indicator. The design resembles old Smiths brand instruments.
Another distinct characteristic is the dark LC display of the DarkEdition. It further increases the harmonic look of the gauge.
Please note: We explicitly stress that readability decreases in cases of direct sunlight. If readability is of primary concern to you, please purchase the standard green display.
A technically identical instrument is also available with an analogue speedometer (please refer to the CLASSIC series).
Scope of Supply
Instrument with approx. 55 cm connector cable, complete wiring, fuse, speedometer sensor M5 x 0,5 fine-pitch thread with 150 cm connector cable, 2x magnets, mini push-button, 3x M4 screws (VA), detailed installation and operating instructions. Please note that temperature and pressure sensors have to be ordered separately (refer to "Accessories").
Specifications
- Mounting diameter: 80 mm
- Overall diameter (bezel): 85 mm
- Depth without cable fitting: 34 mm
- Weight: approx. 230 g
- Mounting: 3 x M4 threaded hole
- Power consumption (in operation): approx. 200 mA (depending on load)
- Power consumption (in standby): 0 mA
- Operating voltage: 9-18 V
- Operating temperature: -20 °C... +80 °C
